PRODUCTNEWS

December 2019/ January 2020


Towns and cities are changing, digitalisation is advancing fast, and lighting plays a key role in it all. Not only does a smart lighting solution save energy costs, it also helps to improve the safety of a town and really bring the place to life.
With the appropriate LED drivers, sensors and communication modules, the SIDEREA outdoor range has everything you need for efficient, safe and innovative outdoor lighting. The latest DALI-2 standard D4i and the Zhaga Book 18-certified interface pave the way for future-proof lighting that is equipped to handle tomorrow’s innovations today. Combined with the gateway and smart city platform from Paradox Engineering, this is one smart outdoor solution that offers much more than just light.

Learn about this and much more in our latest newsletter.



  SIDERIA - Outdoor
_ LCO 14/24/40/60W NFC PRE3
_ Zhaga RF node
_ PSensor SSI 31 2xPIR 8DP DG
_ Zhaga socket

  Industry
_ LCI 75/105W flexC NF lp EXC3

  Retail & Hospitality
_ CLE ADV4
_ EM powerLED BASIC SC 32W SC


  Lighting Controls
_ companionSUITE: new release
_ 4service NFC mobile app



SIDERIA Outdoor

Retail &
                          Hospitality

Outdoor Drivers LCO 14/ 24 /40/ 60 W NFC
                          PRE3

Outdoor drivers LCO 14 / 24 / 40 / 60 W NFC PRE3

Contactless NFC multi-programming with companionSUITE software
Interfaces: NFC, Powered DALI-2, ready2mains, U6Me2
_ Wide temperature range from -40 to +70 °C
_ Wide operating window (2V-out), which covers up to 2,100 lumens



The dimmable DALI LED driver, which is the first to be designed based on the new D4i standard, provides the basis for smart city concepts. The latest DALI standards define aspects such as the provision of operating and diagnostic data. The 24 V auxiliary and the DALI bus power supply designed in accordance with DALI Part 250 also support the direct operation of communication modules and sensors.   more...

Zhaga RF node

Zhaga RF node

Conforms to the latest Zhaga D4i standard
Paradox IPv6 6LoWPAN mesh technology (868 MHz)
_ Self-healing mesh network for reliable and stable operation
_ Designed for harsh environments
_
Life time of up to 100,000 hours (at tc = 72 °C)
_
IP66 degree of protection and impact resistance ≤ IK09


The multimaster controller for integrating into the Paradox Engineering gateway is designed in accordance with the latest DALI specifications D4i Book 250-253, and so enables the control and monitoring of various luminaire data. Several RF nodes build their own mesh network, allowing them to bridge distances of up to 100 metres. The innovative interface, which conforms to the latest Zhaga standard Book 18 Ed.2, enables tool-less installation via plug-and-play – even retrospectively.
  more...


Sensor PSensor SSI 31 2xPIR 8DP DG

Sensor PSensor SSI 31 2xPIR 8DP DG

2 x PIR multisensor for motion and ambient light detection
Easy and flexible installation thanks to Zhaga Book 18 Ed.2-certified interface
_ Rectangular, asymmetrical detection range of up to 35 metres
_ Mains overvoltage protection of up to 10 kV in combination with PRE driver


Two PIR elements give the multisensor a very wide detection range. The sensor offers ambient light and motion detection and has asymmetric lenses, which allow two different zones, such as pedestrian and cycle paths, to be captured and lit separately.
  more...


Zhaga socket

Zhaga socket

The socket designed in accordance with Zhaga Book 18 Ed.2 provides the basis for future-proof outdoor lighting. Luminaires with the socket can be equipped with sensors and nodes in next to no time by means of plug-and-play – either at the time of installation or at a later date. Luminaires can be retrofitted at any time and brought up to date.   more...


New brochure: SIDEREA – Citizen Centric Lighting

SIDEREA - Citizen Centric
                                    Lighting



Download  here


Industry

Office &
                          Education

Driver LCI 75 / 105 W flexC NF lp EXC3

Driver LCI 75 / 105 W flexC NF lp EXC3

Efficiency up to 94 %
Wide operating window: 100-1050 mA
Currents can be set via NFC, ready2mains and I-SELECT 2
_
Extended temperature range: -40 to +80 °C
_
Low inrush current: 5 A/1000 µs / B16: >32 devices
_
Life time of up to 120,000 hours (at ta = 65 °C)



The driver is extremely robust, making it ideal for use in industry. It performs well and with the utmost reliability even under extreme conditions, such as high temperatures and vibrations, and is well-protected against overvoltage. Boasting efficiency of up to 94 percent, the driver is also extremely economical.   more...


Retail & Hospitality

Office & Education
Module CLE ADV4

Module CLE ADV4

Improved system efficacy thanks to chip upgrade
Higher lumen output (190, 220 mm) thanks to new operating mode (HO)
Very good efficacy up to 199 lm/W
_
Optimised life time up to 72,000 hours



The fourth generation of the round advanced modules (ADV4) offers a new operating mode (HO) for the 190 and 220 mm sizes, which enables a considerably higher lumen output. In addition, the modules for wall and ceiling luminaires feature a chip upgrade that significantly improves system efficiency. The modules are available either with a continuous PCB or a space for sensors and small driver connections.   more...

EM powerLED BASIC SC 32 W SC

EM powerLED BASIC SC 32 W SC

Forward voltage: 15-50 V (SELV)
Rated operating time: 1 or 3 hour(s)
Selectable output currents via I-SELECT 2: 350-700 mA



The established combined emergency lighting LED driver for manual testing features a space-saving design and requires minimal wiring work. It is designed to be used with long-life, compact LiFePO4 batteries. As well as the stretched compact housing, there is an optional strain relief which is extremely easy to install.  more...


Lighting Controls

Office
                          & Education

companionSUITE software collection




companionSUITE software collection new release

The latest release features the following additional functions:


Improved interface for chronoSTEP
Data readout in accordance with DALI-2 Part 251 (asset management)
Reset to default
_ Parameter locking via password
_
LED current limits



Tridonic software package companionSUITE supports every single step – from production to quality management.   more...


companionSUITE: 4service NFC mobile app

companionSUITE: 4service NFC mobile app

Set the LED output current
Select the device operating mode (DALI, corridorFUNCTION, chronoSTEP)
Set the DALI short address
_
Copy function for transferring defined driver settings to an identical device
_
Define and activate the chronoSTEP profile and corridorFUNCTION
_
Define the driver behaviour in corridorFUNCTION mode
_
Transfer the deviceGENERATOR configuration
_
Export defective drivers via Memory Bank



As part of the companionSUITE software collection, the 4service NFC app offers an easy and quick way of configuring and analysing LED drivers wirelessly (NFC) on site. This means that street luminaires in particular can be adapted wirelessly with minimal effort. Dimming functions can simply be configured and transferred from deviceGENERATOR.


Apple App Store EM converterLED 50/250V
                                    NiCd/NiMH ST/PRO
